Product advantages

Efficiency: The fastest speed can reach 800 knots/minute, and the operation is flexible and versatile;
The length error is ≤ 2mm, and the length of the product varies when it is not affected by cooking, such as thermal expansion, contraction, and gravitational droop;
Province: (comparison between twisting and tying) ① Province casing: For example, a daily production of 2 tons of 50mm weight for personal intestinal customers can save casing: 1200m/tX casing unit price of 0.5 yuan/t=600 yuan/ton; Save casing costs of 1200 yuan/day, 36000 yuan/month, and 432000 yuan/year; The double wire tying machine can be used within three months; ② Province casing: cable tie 1135X960X1165mm; Twist: 1400X800X1360mm;

Product parameters

总功率及电源 Total power and power supply	14kW / 380V+N+PE/50Hz
灌装机直灌能力Filling machine's direct filling capacity	3000kg/h
带提升原料功能 Improve raw materialfunctionality	提升容积Increase volume:200~250升(rise);最大提升重量Maximum lifting weight250kg
灌装机真空压力Filling machine vacuum pressure	0~ -0.1mpa
最大扎线速度Maximum wire tying speed	800节knots/min
扎线直径规格Cable diameter specification	中14~中40，绕线圈数1.5~5圈number of coils 1.5-5 turns
定量精度-蛋白肠衣Quantitative accuracy-protein casing	±2g/每支香肠，天然肠衣+3g/每支香肠±2g/sausage,naturalcasing±3g/sausage
定长精度Fixed length accuracy	蛋白肠衣+2mm，天然肠衣+3mm(生制品)Protein casing±2mm,naturalcasing±3mm(raw products)
外形尺寸(LxWxH) External Dimension(mm)	860013662253mm(LxWxH)
